Apex Connect

Explore DECT7

Common DECT Specification

• Carrier Spacing: 1.724 MHz
• Time Slots: 2 x 12 (up and down stream)
• Channel Allocation: Dynamic
• Encryption: DECT Standard Cipher with 35-bit initialization vector
• Audio Bandwidth:  300 Hz to 3.4 kHz, Narrow Band, G.726 compression 50 Hz to 7 kHz, Wide Band, G.722 compression

Region 1 Specific Specifications

• Authorized for use in: Canada, USA
• Frequency Bandwidth: 1920 MHz to 1930 MHz
• Number of Carriers: 5
• Total Time Slots: 60 in G.726(narrow band) / 30 in G.722(wide band)
• Average Output Power: 4 mW
• Maximum Output Power: 100 mW
• DECT Range: 800 ft.

Connect to the ComHub for team push-to-talk

• Class: Class 2 Device
• Frequency Bandwidth: 2400 MHz to 2485 MHz
• Maximum Output Power: 2.4mW / 4dBm
• Range: Up to Bluetooth standard 33 feet (10 meters)
• Version: 5.0/4.2 with secure simple pairing

• FCC Part 15
• FCC ID Apex Connect: V9N950140600V1
• IC UPN APEX Connect: 7895A-950140600

Instant voice feedback confirms feature settings and menu selections.

Update Apex Connect firmware to access the newest enhancements.

• 3″ x 3″ x 1″
• 5.8 oz (8.1 oz w/ belt clip)

• Battery: 3.7V rechargeable lithium ion battery
• Battery Life: More than 24 hours at 77°F (25°C)
• Charge time: 4 hours for full discharged battery
• AC Charge Source: Supplied; USB Wall Charger 5V, 2.4A
• DC Charge Source: 5V, 1A minimum, cable supplied
• Over voltage, under voltage, over current and over temperature protection

• IP-Rating: IP67 (watertight up to 1 meter and dust proof)
• Operating temperature: -22°F (-30°C) to +140°F (+60°C)
• Storage temperature: -40°F (-40°C) to +122°F (+50°C)

• Conducted Transients per 7637-2
• Quality Management System ISO 9001:2015

• Humidity per MIL-STD 810F and 810G
• Temperature Shock per MIL-STD 810F and 810G
• Chemical Exposure per MIL-STD 810

• Salt Spray per J1455, Sec. 4.3
• Vibration per J1455, Sec. 4.9
• Conducted Immunity per J1113-11
• Electrostatic Discharge per J1113-13
• Radiated Emissions per J1113-41

UL1642 Standard for Lithium Batteries

UN38.3 UN Transportation Testing for Lithium batteries

• Apex Connect
• Magnetic Belt Clip
• Magnet Clasp
• AC USB Wall Adapter
• USB-C Charging Cable
• DC Charging Adapter
• Quick Start Guide

• 3^rd Party headset device (corded or Bluetooth)
• See our recommended devices to use with Apex Connect here.
